Compact  integrated motor  with RS-422/485 communications interface. Feedback options include open loop,  closed loop or absolute encoder with hMTechnology. IP20 or IP65

  • Motor size: NEMA 23 (57 mm)

  • Standard Torque Version- Holding Torque range: 103 … 242 oz-in (73 … 171 N-cm)

  • High Torque Version - Holding Torque range: 152 … 416 oz-in (107 … 294 N-cm)

  • Input voltage: +12 to +60 VDC

Liberty MDrive 23 Step and Direction

  • General





    Control type

    Pulse/direction input

    Communications interface

    RS-422/485

    Communications features

    MCode OS

    NEMA size

    23 (57 mm)

    Standard Torque range

    oz-in (N-cm)

    103 … 425 (73 … 300)

    High Torque range

    oz-in (N-cm)

    152 … 416 (107 … 294)

    Operating temperature

    [°C] heatsink

    [°C] motor

    85

    100

    IP rating

    IP20
